How To Install .Net Core Runtime In Service Fabric Using Terraform

July 04, 20205 min read •

Photo by [Jefferson Santos](https://unsplash.com/@jefflssantos?utm_source=medium&utm_medium=referral) on [Unsplash](https://unsplash.com?utm_source=medium&utm_medium=referral)

Photo by Jefferson Santos on Unsplash

In this article, I am going to share my own experience and thought process since I could not find existing tutorials on how to do that. Recently, we have decided to install .NET Core runtime in the Service Fabric cluster to reduce the package size deployed to the cluster. It should reduce the deployment time for many .NET Core applications. Currently, we are using self-contained deployments, which result in deploying large packages that take a long time.

First Attempt

In the beginning, I thought that this is a straightforward task to do, but I was so wrong. Why did I think that this is going to be easy? Well, we already had Terraform templates for the Service Fabric cluster and Virtual Machine Scale Sets (VMSS). We also had the .NET Framework 4.8 installation on VMSS via Powershell (.ps1) script added to the Terraform template as an extension to the VMSS.

extension {
    name                       = "InstallDotNet"
    publisher                  = "Microsoft.Compute"
    type                       = "CustomScriptExtension"
    type_handler_version       = "1.8"
    auto_upgrade_minor_version = true
    settings                   = <<EOF
    {
      "fileUris": [
        "https://yourblobstorageaccount.blob.core.windows.net/dotnet48/InstallDotNet-48.ps1"
      ],
      "commandToExecute": "powershell -ExecutionPolicy Unrestricted -File InstallDotNet-48.ps1"
    }
    EOF
  }

First, I decided to look for a .ps1 script that could install the runtime non-interactively. It turned out that Microsoft already had such a script. I thought, great let me download it and add to the existing Terraform VMSS configuration as an additional extension. I did that and the result looked good, so I created a Pull Request (PR). My coworkers reviewed it, and also Terraform validation passed. After completing the PR, the feature branch was merged to the dev branch, and automatic deployment started to the dev environment. As you might probably guess, it did not work quite well. Unfortunately, Azure does not support many extensions of the same type.

Second Attempt

All right, not a big deal, I will add this logic to the existing extension, which installs .NET Framework 4.8. I used the pipe operator to combine multiple .ps1 commands.

powershell -ExecutionPolicy Unrestricted -File InstallDotNet-48.ps1 && powershell -ExecutionPolicy Unrestricted -File dotnet-install.ps1 -Runtime dotnet -Channel 2.1 && powershell -ExecutionPolicy Unrestricted -File dotnet-install.ps1 -Runtime dotnet -Channel 3.1

I changed the Terraform template again and repeated the deployment process. Unfortunately, the deployment failed due to unable to download the needed files for the .NET Core runtime. Something was blocking the download of the files. My next move was to connect to the one of the Virtual Machines (VM) and launch the .NET Core installation .ps1 script manually to check what went wrong. I was able to reproduce the issue. Ok, how can I solve it? I started to research. After searching for some time, I found a possible solution in the documentation: https://docs.microsoft.com/en-us/dotnet/core/tools/dotnet-install-script#examples. Scroll down until “Obtain script and install .NET Core CLI one-liner examples” section.

\# Run a separate PowerShell process because the script calls exit, so it will end the current PowerShell session.
&powershell -NoProfile -ExecutionPolicy unrestricted -Command "\[Net.ServicePointManager\]::SecurityProtocol = \[Net.SecurityProtocolType\]::Tls12; &(\[scriptblock\]::Create((Invoke-WebRequest -UseBasicParsing '[https://dot.net/v1/dotnet-install.ps1'](https://dot.net/v1/dotnet-install.ps1%27)))) <additional install-script args>"

This piece of code below helped to solve the problem since only Ssl3 and Tls security protocols were enabled in the PowerShell session on Windows Server 2016 Datacenter.

[Net.ServicePointManager]::SecurityProtocol = [Net.SecurityProtocolType]::Tls12;

I modified the Terraform template again and repeated the deployment process.

powershell -ExecutionPolicy Unrestricted -File InstallDotNet-48.ps1 && powershell -NoProfile -ExecutionPolicy unrestricted -Command \\"\[Net.ServicePointManager\]::SecurityProtocol = \[Net.SecurityProtocolType\]::Tls12; &(\[scriptblock\]::Create((Invoke-WebRequest -UseBasicParsing '[https://dot.net/v1/dotnet-install.ps1'](https://dot.net/v1/dotnet-install.ps1%27)))) -Runtime dotnet -Channel 2.1 \\" && powershell -NoProfile -ExecutionPolicy unrestricted -Command \\"\[Net.ServicePointManager\]::SecurityProtocol = \[Net.SecurityProtocolType\]::Tls12; &(\[scriptblock\]::Create((Invoke-WebRequest -UseBasicParsing '[https://dot.net/v1/dotnet-install.ps1'](https://dot.net/v1/dotnet-install.ps1%27)))) -Runtime dotnet -Channel 3.1 \\"

This time the deployment finished successfully, but there was another issue to solve.

Third Attempt

It turned out that .NET Core apps expect the runtime to be in C:\Program Files\dotnet directory, but the .NET Core .ps1 installation script installs the runtime in the user profile folder by default.

There are two ways to solve this:

  • Change the installation directory to the C:\Program Files\dotnet.
  • Add the DOTNET_ROOT environment variable with the path to the custom location of the dotnet.exe.

I decided to add the installation directory argument to install it in the default directory. The result looks like this:

extension {
    name                       = "InstallDotNet"
    publisher                  = "Microsoft.Compute"
    type                       = "CustomScriptExtension"
    type_handler_version       = "1.8"
    auto_upgrade_minor_version = true
    settings                   = <<EOF
    {
      "fileUris": [
        "https://yourblobstorageaccount.blob.core.windows.net/dotnet48/InstallDotNet-48.ps1"
      ],
      "commandToExecute": "powershell -ExecutionPolicy Unrestricted -File InstallDotNet-48.ps1 && powershell -NoProfile -ExecutionPolicy unrestricted -Command \"[Net.ServicePointManager]::SecurityProtocol = [Net.SecurityProtocolType]::Tls12; &([scriptblock]::Create((Invoke-WebRequest -UseBasicParsing 'https://dot.net/v1/dotnet-install.ps1'))) -Runtime dotnet -Channel 2.1 -InstallDir 'C:\\Program Files\\dotnet' \" && powershell -NoProfile -ExecutionPolicy unrestricted -Command \"[Net.ServicePointManager]::SecurityProtocol = [Net.SecurityProtocolType]::Tls12; &([scriptblock]::Create((Invoke-WebRequest -UseBasicParsing 'https://dot.net/v1/dotnet-install.ps1'))) -Runtime dotnet -Channel 3.1 -InstallDir 'C:\\Program Files\\dotnet' \""
    }
    EOF
  }

And this finally worked! My colleague made sure that it works by deploying the .NET Core app without passing --self-contained true parameter to the dotnet publish command.

Conclusion

Installing the .NET Core runtime in the Service Fabric cluster turned out to be not so straight forward task as it seemed in the beginning. The main reason is the lack of documentation and examples on how to do it via Terraform templates. Thanks for reading!

Resources

https://docs.microsoft.com/en-us/dotnet/core/tools/dotnet-install-script#examples

https://www.terraform.io/docs/providers/azurerm/r/service_fabric_cluster.html
